15KW Microwave Generator
The 15kW microwave power supply delivers stable, high-frequency output with precise power control and high efficiency. Designed for industrial heating, plasma processes, and scientific applications, it offers reliable continuous operation with advanced protection features.
Product Description
Product Model: ACME/WF153-S
Operating Stability: Better than 1%
Spectrum Width: Approx. 1.5MHz
Microwave Frequency: 2450MHz±15MHz
Microwave Output Interface: BJ22 or BJ26 optional
Magnetron: CK2091
Control Method: Local control/Communication
Cooling Method: Water cooling
Dimensions (W*D*H):
Anode High Voltage Power Supply: 482mm*626mm*177mm
Microwave Head (including circulator): 370mm*570mm*290mm
