100KW Microwave Generator
The 100kW microwave power supply delivers ultra-high-power, stable high-frequency output with precise control and outstanding efficiency. Engineered for large-scale industrial heating, plasma systems, and advanced scientific applications, it ensures reliable continuous operation with comprehensive protection and intelligent monitoring features.
Product Description
Product Model: ACME/WF104-L
Microwave Output Power: 4kW~100kW continuously adjustable
Operating Stability: Better than 0.5%
Microwave Frequency: 915MHz±10MHz
Spectrum Width: 1MHz
Microwave Output Interface: BJ9
Magnetron: CK2152
Control Method: Local control/Communication
Cooling Method: Water cooling
Dimensions (W*D*H):
Anode Power Supply Cabinet: 722mm*900mm*1765mm
Microwave Head (excluding Circulator): 890mm*610mm*930mm
