75kW Microwave Generator
The 75kW microwave power supply delivers high-power, stable high-frequency output with precise control and excellent efficiency. Designed for large-scale industrial heating, plasma processes, and advanced research, it provides reliable continuous operation with comprehensive protection and monitoring functions.
Product Description
Product Model: ACME/WF753-L
Microwave Output Power: 3kW~75kW continuously adjustable
Operating Stability: Better than 0.5%
Microwave Frequency: 915MHz±10MHz
Spectrum Width: 1MHz
Microwave Output Interface: BJ9
Magnetron: CK2031
Control Method: Local control/Communication
Cooling Method: Water cooling
Dimensions (W*D*H):
Anode Power Supply Cabinet: 595mm*800mm*1510mm
Microwave Head (excluding Circulator): 890mm*610mm*930mm
